ENCORE WIRE

REEL PAYOFF

No jack stand needed. Pull wire directly from the reel and save 70% on your total set up time!

​

FEATURES

• THE INDUSTRY’S FIRST SELF-SPINNING WOODEN REEL! No jack-stand needed! The Reel Payoff allows you to pull directly from the pallet. When off the pallet, the Reel Payoff rotates within its own axis for 360-degree maneuverability; perfect for small spaces.

• CUSTOMIZATION Whether your job calls for single conductors or parallels, we can customize your Reel Payoff using our custom colors to fit any job you come across.

• UPGRADED FEATURES Engineered polymer spacers placed between reel flanges prevent seizing due to moisture and allow larger reels to handle heavier weights more easily. Reel legs lock inner flange in place during loading and transit. Legs also work as chocks off the pallet.

• ROLL-OFF POSITION All Reel Payoffs are shipped in roll-off position, reducing material handling costs and possible damage.

• 4-WAY PALLET Pull straight from the pallet with no tools! Position our exclusive 4-way pallet in your desired location and get ready to pull!

​

Click HERE

for more information on the

Encore Wire Reel Payoff

​

CALL/EMAIL FOR DETAILS:

(503) 238 - 8800

Roslyn Ready

roslyn@cascadewestern.com

ELLIS CABLE CLEATS

Vulcan+TM

​

Standard Duty Compact Stainless Steel Cable Cleat, for cables in single, trefoil or quad formation. The Ellis Vulcan+ cable cleat has been designed, developed, tested and manufactured in accordance with IEC 61914 (cable cleats for electrical installations). The cleat is available in a range of sizes with range taking ability to suit single cables, cables in trefoil formation or cables in quad formation. The frame of the cleat is manufactured from corrosion resistant 316L grade stainless steel, the cable is supported by a liner manufactured form a low smoke zero halogen (LSOH) material. The closure fixings are manufactured from A4-70 grade stainless steel. Vulcan+ can be fixed to the supporting structure by either one or two M10 fixings. Non standard cleat designs can be supplied upon request.

​

FEATURES

• 316L stainless steel frame and fixings

• Soft LSF polymeric liner protects cable sheath

• Captive closure fixings for fast install

• Short circuit and mechanically tested to IEC 61914

• ABS and DNV type approved and also UL Listed

​

Click HERE

for more information on the

Ellis Cable Cleats Vulcan+

​

CALL/EMAIL FOR DETAILS:

(503) 238 - 8800

Lesley Killaby

lesley@cascadewestern.com

​

CSH SERIES | COLD SHRINK HAMMERHEAD

​

We've taken our industry-leading Deadbreak Elbow design and given it a game-changing transformation. The Cold Shrink Hammerhead is the next generation Deadbreak Elbow. Injection molded from a variety of specially-formulated cold-shrinkable materials, the CSH makes installation simpler, more reliable and still exceeds industry standards.

​

FEATURES​

• All-In-One Solution: The CSH is range-taking and includes an integral jacket seal, providing a complete solution in a simple package. Three separate components have been elegantly combined into a single design.

• 100% EPDM: Richards Cold Shrink Products are molded from 100% EPDM, a proven material in underground electrical applications for decades. This proprietary formulation of Cold Shrink EPDM is produced in-house. To achieve maximum durability in underground environments, the CSH features a fully-integrated, oil-resistant EPDM jacket that provides outstanding mechanical impact/tear resistance.

• Easy Installation: We’ve optimized our design to minimize installation time, complexity, and overall cost. No more cable adapter and no more separate jacket seal kit. The cold shrink Cable Entrance eliminates problems that arise when sliding traditional interference-fit Deadbreak elbows into position. This ergonomic improvement substantially simplifies positioning/aligning the lug in the CSH housing.

• Designed, Molded & Tested in the USA: Our team is intimately involved in everything from material development, product and mold design, and production. This allows us to control every aspect of the design, down to the smallest detail.

​

​

​

Click HERE

for more information on the

Richards Mfg Cold Shrink Hammerhead

​

CALL/EMAIL FOR DETAILS:

(503) 238 - 8800

Lesley Killaby

lesley@cascadewestern.com
